XTL-800GN AUTO LOADER

Name: XTL-800GN AUTO LOADER
Brand: SONLY
SKU: a6a870504668234.00930992

Product Code a6a870504668234.00930992

Precision Engineering Reliable industrial accuracy

Energy Efficiency Optimized power performance

Global Technical Support Technical service worldwide

Machine configuration can be discussed according to your production requirements.

Product Tags

Machine Details

Product Overview

XTL-800GN AUTO LOADER

Technical Data

Technical parameters and machine configuration for this model.

Model	XTL-800GN
Machine Type	Vacuum Auto Loader
Motor Type	Induction Motor
Motor Power	1.5 kW (3 Phase)
Conveying Capacity	550 kg/h
Maximum Static Wind Pressure	2000 mmAq
Filter Size	Ø188 × 115H mm
Material Hopper Capacity	6.5 L
Conveying Pipe Diameter	Ø38 mm
Main Body Dimensions	700 × 370 × 500 mm
Material Hopper Dimensions	430 × 440 × 295 mm
Main Body Weight	65 kg
Material Hopper Weight	6 kg
Hopper Material	Stainless Steel
Control System	Microcomputer Control
Protection	Motor Overload Protection & Material Shortage Alarm
Application	Automatic Conveying of Plastic Granules for Injection Molding and Plastic Processing Machines

Interested in this machine?

Tell our technical team about your product, mold and production requirements to select the right injection molding solution.
